| Total Area |
616.25 SQ Ft |
| Live Load (Deck & Stairs) |
= 60 PSF |
| Footer Depth |
= 36" |
| Beam Size |
2-2x10 |
| Deck Beams |
Internal |
| Joist Size |
2x10 |
| Joist Spacing |
12" OC |
| Post Size |
4x4 |
| Post Setting |
On top of footers |
| Decking |
1x6 T&G (extruded plastic) |
| Decking Spacing |
Zero |
| Rail Section Size |
4.5’ to 5.5’ varies |
| Rail Cap |
1x6 (extruded plastic) |
| Rail Spindles |
2x2 (extruded plastic) chamfered |
| Deck Screws |
Stainless |
| Fascia Size |
1/2x8 |
| Hot Tub Access Panel |
7'6" x 2'6" to left of tub (tub is actually 7'6" x 7'6") |
| Hot Tub Footer |
Detached from deck, on gravel & PT 4x4 pad |
